Economical SMD LEDs300w High Mast Tower Lighting IP66 Slim Exterior Led Floodlights
Slim Housing Design with Good Heating Solution, Power Range from 30watt to 300watt,
Designed for Outdoor Using,
Such as Parking Area, Sports Stadium, Hall, Airport Apron, Square, etc.
| Model | GY1714TG | GY1916TG | GY2824TG | GY3529TG | GY3529TG | GY6540TG |
| Power(W) | 30 | 50 | 100 | 150 | 200 | 300 |
| Lighting Efficiency (lm/W) | 100lm/w |
| CCT (K) | 3000-6500K |
| PF | ＞0.95 |
| Input Voltage (V) | AC100-300V |
| CRI(Ra) | 80 |
| Frequency | 50/60Hz |
| IP Rating | IP66 |
| Class | CLASS I |
| Lightning Protection Grade | 4KV |
| Working Temperature(℃) | -20～45 |
Operating Humidity
(RH) | 20 ～95 % |
| Lamp Dimension (mm) | 190*160*30 | 210*180*30 | 280*240*30 | 350*295*36 | 420*300*36 | 468*358*40 |
| Net Weight (Kg) | 0.84 | 1.05 | 1.86 | 2.8 | 4 | 5.5 |
| Material | Die-casting Aluminium Alloy + Glass |
【Durable Material & IP66 Waterproof & Excellent Dissipation】:
The LED floodlight are made of heavy-duty die-cast aluminum housing with epoxy coating and a tough poly-carbonate prismatic lens. The floodlight has an Ingress Protection rating of an IP66 rating for outdoor wet locations which can be widely used; With a heat dissipation system and 12KV Surge system, enhances the 500W LED light in heat dissipation to ensure excellent heat dissipation and long-lasting performance.
【Easy to Install 】:
The stadium floodlight comes with U-bracket Mounting, it can be installed in 3 minutes. To a great extent, it saves your valuable time. This is ideal for lighting up big stadiums and sports facilities such as parking lots, dock, basketball courts, tennis courts and soccer fields, or other large areas that require a substantial amount of light.
Fast Cooling Design
The housing is made of die-cast aluminum, which can absorb heat efficiently generated by the LEDs, thereby increasing the lifespan of the LEDs. The convective structure on the back of the housing dissipates the heat effectively. All are designed for fast heat-dissipating purpose.
IP65 WATERPROOF
Highly light transmittance, impact-resistant tempered glass panel perfectly fits the aluminum alloy body, achieving IP65 waterproof and dustproof rating, ensuring your led outdoor flood light survives the harshest weather and works well.
LED floodlight is widely used in:
Outdoor lighting
Architectural lighting
Storage spaces
Golf courses
Landscape lighting
High mast lighting
Gym lighting
Storage warehouse lighting
Façade lighting
Tunnel lighting
Square, Park, Wall of buildings, Church, Hotel, Bridge, Tree, Public areas, etc.
QC
GYLED has a very strict Quality Control System, from checking and evaluation of incoming materials to the delivery of products, each item will be checked and tested several times.
MOQ: 1 CARTON
ABOUT US
We, Shanxi Guangyu LED Lighting Co., Ltd, established in 1988, is a professional LED lighting products manufacturer in the Shanxi province of China. Our Sales office and R&D center both are in Shanghai. GYLED is your provider of premier quality LED lighting products and solutions. Our main products are LED Industrial Highbay lights, LED Flood Area lights, LED Streetlights. our products comply with CE, RoHS, ERP, GS, SAA, UL, cUL, and CCC certificates with our long-term great efforts. with our long-term great efforts, We aim at focusing on the best products with high quality and low cost.
Professional Packaging
• Foam Protection to Withstand Harsh Transportation and Impact
• Carton and Pallet with Foam and Cling Wrap to Withstand Impact, High Humidity in Containers, and Rainy Weather
• To Guarantee an Intact Condition when Receiving the Goods
Shipment
1. DHL(a big discount)
2. TNT/FedEx/UPS
3. DHL Airway express. About 3-5days you can get them by the door of your home or office.
4. Seaway.15-25 days. It will definitely save your shipping cost for the large order.
